Azbil Corporation Introduction
Model MGG10C/14C - MagneW FLEX+/PLUS+ Converter 1-5
System conguration WITHOUT the communication function
Figure 1-3 shows a sample system conguration without the communication. In this
system, the device measures the ow rate and outputs analog 4 to 20mA DC signal to
the Host Control System.
A
C or DC
power
supply
Device
Host
control
system
Figure 1-3 System conguration of analog output WITHOUT communication
function
Smart Electromagnetic Flowmeter (device)
Measures ow rate and outputs an analog signal.
