Azbil MagneW FLEX+/PLUS+ MGG10C User Manual

Model MGG10C/14C - MagneW FLEX+/PLUS+ Converter 1-1
Chapter 1: Introduction
This chapter contains an overview of the model MGG10C/MGG14C MagneW FLEX+/
PLUS+ Flowmeter. It provides denitions for all the major parts of the converter.
MagneW FLEX+/PLUS+ Flowmeter
Thank you for purchasing the Azbil Corporation model MGG10C/MGG14C
Flowmeter. This system features:
• Digital panel display
• Intuitive, versatile operator interface with large characters and backlit liquid crystal
display (LCD)
• I/O Capacity
Main components
The model MGG10C/MGG14C MagneW FLEX+/PLUS+ Flowmeter consists of a
detector and a converter which operate on the principles of Faraday’s law.
Integral - The converter is mounted directly on the detector and they are installed as
an integrated unit on the uid pipe.
Remote - The converter and detector are installed separately and connected together
via cables
AC power supply
Pulse output
Contact input/output
Analog output
Digital output
Fluid
Detecto
r
Converter
Figure 1-1 Integral System

Azbil MagneW FLEX+/PLUS+ MGG10C Specifications

General

Brand	Azbil
Model	MagneW FLEX+/PLUS+ MGG10C
Category	Media Converter
Language	English
