Table 1: Quick Start Parameters for Vector Plus and Vector VII Applications (cont'd.)
Parameter Name
Default
Information
Decel Seconds
5.0 Seconds
Deceleration ramp time, in
seconds, for the Vector Plus drive
from Max Frequency to stopped.
For ESP applications, maximum
recommended Decel Seconds is
10.0.
Motor Overload
0.0 Amps
Set to motor nameplate amps.
This setting is used to protect
the motor from heat damage
associated with excess loading.
Note that the default setting of 0.0
Amps requires this parameter be
set prior to running the drive.
Motor Underload
-9,999 Amps
This setting is used to protect
the motor from heat damage
associated with the loss of cooling
fluid moving by the motor caused
by well pump-off. Note that the
default setting of -9999 Amps
requires this parameter be set
prior to running the drive.
Motor Temp High Limit
0.0 °F
Downhole Tool Motor Temperature
High Limit. Drive will Fault if the
Motor Temperature exceeds the
specified limit. Note that the
trigger is Not In Use by default.
The trigger will be set to “In Use”
automatically when the Limit is
changed.
Intake Temp High Limit
0.0 °F
Downhole Tool Intake
Temperature High Limit. Drive will
Fault if the temperature exceeds
the specified limit.
IntakePressLow Limit
0.0 Psi
Downhole Tool Intake Pressure
Low Limit. Drive will Fault if the
Intake Pressure drops below the
specified limit.
