Table 14: ST-3704 RTD Connections (cont'd.)
Pin No.
Description
3
RTD Ch#1+
4
RTD Ch#1-
5
RTD Ch#2+
6
RTD Ch#2-
7
RTD Ch#3+
8
RTD Ch#3-
9
AGND
10
AGND
Table 15: ST-3708 RTD Connections
Pin No.
Description
1
RTD Ch#0+
2
RTD Ch#0-
3
RTD Ch#1+
4
RTD Ch#1-
5
RTD Ch#2+
6
RTD Ch#2-
7
RTD Ch#3+
8
RTD Ch#3-
9
AGND
10
AGND
11
RTD Ch#4+
12
RTD Ch#4-
13
RTD Ch#5+
14
RTD Ch#5-
15
RTD Ch#6+
16
RTD Ch#6-
17
RTD Ch#7+
18
RTD Ch#7-
