Page 43 of 277
Figure 17: ST-2744 Interface Design, page 43 shows the interface design for ST-2744.
Figure 17: ST-2744 Interface Design
Figure 18: ST-3214 Interface Design, page 43 shows the interface design for ST-3214.
Figure 18: ST-3214 Interface Design
Table 14: ST-3704 RTD Connections
Pin No.
Description
1
RTD Ch#0+
2
RTD Ch#0-
