9. ICMP
Dual S tream 3G HD-SDI s ignal
Dual Stream 3G
3Gb/s
HD 4:2:2 Signal #1
and
HD 4:2:2 Signal #2
Dual Stream 3G is a specic variant of the 3G signal whic h combines two completely s eparate 4:2:2 image streams into a single 3G
signal. This can be used to transmit stereoscopic streams by keeping the left and right eye signals together.
SMPTE 292M STANDARD 1.485 Gb/s HD-SDI SIGNALS
Standard HD-SDI (SMPTE 292M) formats
SMPTE Standard Source Resolution Frame Rate Display Rat e Scan Type
SMPTE 296M 1280 x 720 23.976
24
25
29.970
30
50
59.940
60
23.976
24
25
29.970
30
50
59.940
60
Progressive
Y C b Cr 4:2:2 10-Bit
SMPTE 274M
SMPTE 428-8
1920 x 1080
2048 x 1080
23.976
24
25
29.97
30
23.976
24
25
29.97
30
Progressive
Y C b Cr 4:2:2 10-Bit
SMPTE 274M
SMPTE 428-9
(SMPTE RP211)
1920 x 1080
2048 x 1080
23.976
24
25
29.97
30
23.976
24
25
29.97
30
Segmented frame
Y C b Cr 4:2:2 10-Bit
SMPTE 274M
1920 x 1080 25
29.970
30
50
59.940
60
Interlaced
Y C b Cr 4:2:2 10-Bit
Dual-Link HD-SDI (SM PTE 372M ) formats
SMPTE Standard Source Resolution
Frame Rate Display Rate
Scan Typ e
SMPTE 274M
SMPTE 428-8
1920 x 1080
2048 x 1080
23.976
24
25
29.970
30
23.976
24
25
29.970
30
Progressive
Y Cb Cr 4:2:2 12-Bit only
Y Cb Cr 4:4:4 10 or 12-Bit
RGB (XYZ) 4:4:4 10 or 12-Bit
R5906753 DPXK BLP SERIES 20/11/2017 101
