12. Removal and installation of the projector covers
12. R EMOVAL AND INS TALLATION OF THE PROJECTOR
COVERS
WARNING: All procedures in this chapter may only be performed by “qualified service technicians” .
WARNING: Always switch off the projector and unplug t he power cord before removing one o f the covers,
unless otherwise stated.
Overview
• Removal of the light source cover
• Removal of the rear cover
• Removal of the input cover
• Removal of the front cover
• Removal of the side c over
• Installation of the front cover
• Installation of the input cover
• Installation of the light source cover
• Installation of the rear cover
• Installation of the side cover
Location of the covers
1
2
3
4
5
Image 12-1
1 Light source cover
2 Input cover
3 Front cover
