14. Maintenance
Max
Min
1
2
Image 14-8
Cooling liquid check
1Maxlevel
2 Min le vel
If the current liquid cooling level is somewhere between Min and Max, then no a ction should be taken.
If the current liquid cooling level is approaching the Min lev el point, than check for leakage in the cooling system prior starting
the refill procedure.
If you cannot see the level, open the filler cap and shine a torch into the reservoir
14.9 Cooling liquid refill
WARNING: This procedure may only be performed by qualified technical service personn el.
Order info cooling liquid
B1909086K : bottle of 1 liter cooling liquid.
Necessary parts
Cooling liquid
How to refill
1. Remove the side cover, "Removal of the side cover", page 126.
2. O pen the filler cap by turning it anti clockwise.
R5906753 DPXK BLP SERIES 20/11/2017
145
