9. ICMP
Functionality
8
HDMI A (B)
HDMI 2.0 connector to connect a video source.
NOTE: It is recommended to use the HDMI 2.0 ports for faster transfer of video and audio data.
9
3G-SDI A (B)
SDI connector to co nnect a v ideo source.
10
HDMI
HDMI 1.4 connector to connect a video source.
11
DisplayPort A (B)
DisplayPort connector to connect a video source.
9.5 ICMP DisplayPort specifications
DisplayPort
Digital display interface developed by the Video Electronics Standards A ss ociation (VESA). This royalty-free interface
is primarily used to c onnect a video source to a display device such as a c omputer monitor, though it can also be us ed
to transmit audio, USB, and other forms of data. V ES A designed it to replace VGA, DVI, and FPD-Link. Backward
compatibility to VGA and DVI by using active adapter dongles enables users to use D isplayP ort fitted video sources
without replacing existing display devices.
HDCP
High-bandwidth Digital Content Protection is a form of digital copy protection dev eloped by Intel Corporation to p revent
copying of digital audio and v ideo content as it travels across DisplayPort, Digital Visual Interface (DV I), High-Definition
Multimedia Interface (HDMI), G igabit Video Interface (GVIF), or Unified Display Interface (UDI) connections, even if
such copy ing would be permitted by fair use laws. The specification is proprietary, and implementing HDCP requires
a license.
DisplayPort specifications
Supported Modes:
• DP1.1a, 4-lanes RBR/HBR
• Audio : yes
• Content Protection : HDCP1.4
• Color Depth : 8 bit/component and 10 bit/component.
• 3D-stereo mode : frame sequential (embedded stereosync on DP required from the source)
DisplayPort A and DisplayPort B accept the following video-timings:
2D Formats / Single DP Color depth Port Display Mode
640 x 480 @ 60 fps 8 bpc, 10 bpc Single 2D
800 x 600 @ 60 fps 8 bpc, 10 bpc Single 2D
1600 x 1200 @ 60 fps 8 bpc, 10 bpc Single 2D
1280 x 800 @ 60 fps 8 bpc, 10 bpc Single 2D
1280 x 720 @ 60 fps 8 bpc, 10 bpc Single 2D
1680 x 1050 @ 60 fps 8 bpc, 10 bpc Single 2D
1920 x 1080 @ 60 fps 8 bpc, 10 bpc Single 2D
1920 x 1200 @ 60 fps 8 bpc, 10 bpc Single 2D
98
R5906753 DPXK BLP SERIES 20/11/2017
