12. Removal and installation of the projector covers
1
1
2
2
Image 12-19
Mount rear cover
2. S ecure the cover by fastening the captive screw at the bottom of the rear cover (2).
12.10 Installation of the side cover
How to install
1. P lace the top of the side cover on its place.
Close t he cover as follow:
a) Gently move the bottom side of the cover towards the projector
b) P ush both lock to each other and pus h at the same time the cover against the projector frame.
c) Release both locks so that they lock in their rec eivers.
