6. Physical installation stand alone cooler
Image 6-15
6.7 Insert the cooler un its
Necessary tools
Flat screwdriver
Before you start
Check if the two indicated screws (reference 1) are present. If it is the case, remove this screws.
The use of these screws m ay beco me necessary to fixate the coole
r in the c ooler assembly when the captive screws (reference 2)
does not work.
1
2
1
2
Image 6-16
How to mount
1. S lide the first co oler unit in t he c ooler h ousing.
58
R5906753 DPXK BLP SERIES 20/11/2017
