18. Specifications

18.6 Dimensions of the DPxK-xxBLP

Dimensions

754 572

675

37.5

41.5

456

219

381.5

604

min. 31

74

721

504

859

188

82

454

1129

Image 18-1

Dimens ions given in millimete rs.

R5906753 DPXK BLP SERIES 20/11/2017 169
