17. Pin configurations
Pin Name Pin Name
7
CONN_SYNC +
15
-
8
3D Input Reference +
17.3 Pin cong urations of the ICMP communication ports
RJ-45 pin conguration
P1P8
Image 17-3
Audio Channels:
AUDIO-AES 1-8
Audio ch annel AES pair RJ-45 pin
1+ 11, 2
1- 2
2+ 33, 4
2- 6
3+ 45, 6
3-
5
4+
7
7, 8
4- 8
AUDIO-AES 9-16
Audio ch annel AES pair RJ-45 pin
5+
1
9, 10
5-
2
6+ 311, 12
6- 6
7+
4
13, 14
7- 5
8+
7
15, 16
8- 8
General Purpose Output:
GPO 1-4
Denition
RJ-45 pin
EXT_GPOU T_1_P
1
EXT_GPOU T_1_N
2
EXT_GPOU T_2_P
3
EXT_GPOU T_2_N
4
EXT_GPOU T_3_P
5
EXT_GPOU T_3_N
6
162 R5906753 DPXK BLP SERIES 20/11/2017
