9. ICMP
HDMI 2.0 Supported Audio Formats
Format
Sample Rate Sample coding
Bit depth
2.0
2.1
5.1
7.1
32
44.1
48
88.2
96
L-PCM
16
20
24
HDMI 2.0 Supported Dual (Tw in) Link Formats (2D formats only)
Format Frame Rate
Color coding
Bit depth
1920x1080
2048x1080
23.976, 24, 25, 29.97, 30, 50,
59.94, 60
RGB
YCbCr 4:4:4
YCbCr 4:2:2
8
3840x2160
4096x2160
23.976, 24, 25, 29.97, 30, 50,
59.94, 60
RGB
YCbCr 4:4:4
YCbCr 4:2:2
8
In Dual (Twin) Link both HDMI2 inputs (port A & port B) should have to same Format, Frame Rate and Color
coding.
Port A should contain the 8 most signicant bits of the pixel data, where port B sh ould co ntain the 8 least
signicant bits of the pixel data. T he pixel data w ill be reconstructed u sing the al
l 8 bits of port A and using
the 4 mo st signicantbitsofportB.
HDMI 2.0 Supported Passive 3D Formats (3D formats only)
Format Frame Rate
Color coding
Bit depth
1920x1080
2048x1080
24, 30
RGB
YCbCr 4:4:4
YCbCr 4:2:2
8
10
12
1920x1080
2048x1080
60
RGB
YCbCr 4:4:4
YCbCr 4:2:2
8
3840x2160
4096x2160
24, 30
RGB
YCbCr 4:4:4
YCbCr 4:2:2
8
In Passive 3D HDM I2 input port A should contain the pixel data of Left Eye and HDMI2 input port B should
contain the p ixel data for Right Eye.
9.8 ICMP H DMI 1.4 specications
HDMI
HDMI (High-Denition Multimedia Interface) is a compac t audio/video interface for transferring uncompressed video
data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a com -
patible computer monitor, v ideo projector, digital television, or digital audio device. HDMI is a digital replacement for
existing analog video standards.
HDMI 1.4 specications
HDMI1.4a, including HDCP1.4
R5906753 DPXK BLP SERIES 20/11/2017 105
