9. ICMP
9.9 ICMP status LEDs
ICMP status LEDs and Reset button
LEDs on ICMP front panel give information on the s tatus of the device.
1
2
Image 9-9
Status overview P W R/ERROR and READY LED s:
1 2
PWR/ERROR RE ADY ICMP Status
Off Off Turned off
Red
Off Board reset or FIPS error
Blinking Green Off
Boot loader
Blinking Green B linking Orange Operating System start up
Blinking Green Orange Security Manager - Image Integrity tests
Blinking Green
Blinking Yellow
Security Manager - Self Test
Blinking Green Yellow Security Manager - FPG A self-test
Green B linking Green Starting Applications
Green Green
Applications started in no rmal mo de
Green Orange
Applications started in degrad ed mode
Blinking R ed Off FIPS erro r
Green B linking Orange
Update ongoing
Orange Orange
Update done
R5906753 DPXK BLP SERIES 20/11/2017 107
