14. Maintenance
Image 14-4
Bottom back dust filter
Clean the dust filter
1. Remove most contamination w ith a vacuum cleaner in an other room or outside.
2. B low remaining dust away with compressed air in an o ther room or outside.
These dust filters are fragile. Clean them gently!
Mount the dust filters
1. Insert the dust filter with the handle upwards. Small filter at the back, big filter at the front.
2. P ush the filters completely in until they click into position.
3. Reinstall the side cover.
14.3 Check the cooler dust filters
How to check
1. Remove both fixation screws (capt ive screw s) a n d ta ke off th e cover plate.
1
Image 14-5
2. S lide out the filter.
R5906753 DPXK BLP SERIES 20/11/2017 141
