8. Input & communication
8. INPUT & COMMUNICATION
Overview
• Introduction
• Local keypad of the D PxK -xxBLP
• Integrated Cinema P rocessor (ICP )
• HD-SDI Input Module ( optional)
• Quad 3G -SDI Input Module (op tional)
• Integrated Media Bloc k/Server (optional)
• Cinema C o ntroller of the DPxK-xxBL P
8.1 Introduction
General
The Input & Comm unication side of the DP xK-xxBLP consists of a Loc al Keypad and a card c age with four slots. T he rear side of
the projector is equipped with a t ail light wh ich reflects the status of the projector.
Depending on the projec tor configuration the projector card cage is e quipped with an ICP or ICMP. See illustration below. In case
an ICP is installed then an IM B, IMS, or HDSDI input m odule can be optionally inserted into the slot below the ICP. Note that all
information about the ICMP is gathered into one separated chapter called ICMP.
1
5
4
1
3
2
4
Image 8-1
1 Fan Control Board (F CB).
2 Integrated Cinema Processor (ICP).
3 Optional slot for either IMB, IMS or HD-SDI input module.
4 Barco Cinema Controller.
5 Barco ICMP (inserted in ICP slot and optional slot).
CAUTION: A unit ma y only be removed from the card c a ge by q ua lified service personnel. Removing one of
the boards (except for the Cinema Controller) will result in an authorization request upon starting.
R5906753 DPXK BLP SERIES 20/11/2017 79
