Index
Lens Holder front plate 77
Focus 69
G
General 15
General considerations 5
General Purpose I/O 159
GPI 96
GPIO 159
GPO 96
H
Hazard distance 14
Modifying optics 14
Hazard Distance 11, 13
Hazardous Chemicals 10
Hazards 175
HD-SDI 82
Front panel 82
HD-SDI settings 82
HDD 95–96, 110–111
About 95
Degrade mode 95
RAID broken 95
RAID recovery 95
Remove 110–111
Storage 95
Storage capacity 95
Validated list 96
HDMI 98
HDMI 1.4 105
Specifications 105
HDMI 2.0 98, 103
Specifications 103
High Brightness precautions 11
I
ICMP 93
ICMP HD D 108
Status LEDs 108
Troubleshooting 108
ICMP reset 109
ICMPintroduction 93
ICP board 81
IMB 89
Important s afety instructions 6
Importer 176
IMS 89
Initial inspection 22
Input 79
Input & c omm unication 79–80, 85, 90
Communication ports 90
Input ports 9 0
Introduction 79
Local keypad 80
Quad 3G-SDI input 8 5
Installation 23–24, 29–32, 34, 37, 51
Access power connection 29
Installation 24
Adjustments 24
Power connection 32
Power input setup 30
Power loop through 34
Power net 31
Process 23–24
Cooler, stand alone 24
Cooler, top pack 23
Projector 23
Stand alone cooler 51
Top cooler 37
UPS connection 34
Installation requirements 15–16
Projector weight 16
Integrated Cinem a P rocessor 81
Integrated Media Block 89
Integrated Media Server 89
Internal clock 109
L
LAN 96
Lens 65, 68–70, 74, 144
Back focal length 70
Cleaning 144
Focus 69
Installation 65
Remove 68
Scheimpflug 74
Shift 69
Zoom 69
Lens holder 63
holder 63
lens 63
Lens H older 77
Front plate 77
lens selection 64
Lenses 63
Available 63
M
Maintenance 137, 139
3 m onth 137
Maintenance program 137
1 M onth 137
Mechanical check 22
Mount protection grid for the LCM cooler modules (option) 61
N
Network Time Protocol 109
Notice on optical radiation 5
Optical radiation 5
Notice on safety 5
O
Own e r’s re co rd 6
P
Package 17
Content 17
Pedestal 170
Dimensions 170
Physical installation 27
Projector 27
Pin configuration 160 , 164
Comm unication ports 160
Inputs 164
Pin configurations 159, 162
ICMP 162
Power connection 32
Installation 32
Power input setup 30
Power loop through 34
Installation 34
Product safety labels 10
Production 176
Projector 171
Air inlets 171
Air outlets 171
Q
Quad 3G-SDI input 85
180
R5906753 DPXK BLP SERIES 20/11/2017
