2. General
Image 2-12
4. Loosen the banding by pulling the free end o f the banding loop in the clip.
Take off the upper carton plate (1)
Remove from the wooden pallet (2)
1
2
Image 2-13
5. Take the projector from the w oode n boa rd by gripping the bottom of the projector an d plac e the projector on the pede stal.
Image 2-14
Save the original shipping carton and p acking material, they will be necessary if you ever h ave to ship yo ur
projector. Fo r maximum protection, repack you r projector as it w as originally packed at the factory.
R5906753 DPXK BLP SERIES 20/11/2017 21
