5. Physical installation top cooler
1
2
1
2
Image 5-16
How to mount
1. S lide the first co oler unit in t he c ooler h ousing.
3
Image 5-17
2. S lide the second c ooler unit in the cooler housing.
3. F ixate both units by closing the both captive screws (reference 3).
Note: When sliding in the cooler units, it is possible that the ca ptive s crew cannot be closed. See wo rk around.
Work around for captive screw
1. Remove the ca ptive screws of both cooler units.
R5906753 DPXK BLP SERIES 20/11/2017
47
