6. Physical installation stand alone cooler
Addition of the metal grid will have a very slight impact to the cooling performance and hence the lifetime of
the laser light source. .
Necessary tools
Flat screwdriver
How to mount
1. S lide the grid (reference 1 image 6-21) in the fixation tabs (reference 2 image 6-21).
2. F ix the grid with the two fixation screws (reference 3 image 6-21).
62
R5906753 DPXK BLP SERIES 20/11/2017
