Cadex C8000 - Page 287

C8000 Battery Testing System User Manual
5 Status Messages 275
36
LCU READY
LOAD CAPTURE UNIT IS CONNECTED AND FUNCTIONAL
37
RESERVED
RESERVED
50
RESERVED
RESERVED
51
RESERVED
RESERVED
107
RESERVED
RESERVED
108
RESERVED
RESERVED
109
RESERVED
RESERVED
110
RESERVED
RESERVED
111
RESERVED
RESERVED
112
CELL MISMATCH
CELLS ARE REACHING FULL CHARGE AT DIFFERENT TIMES
SO THE NEGATIVE SLOPE IS NOT WELL DEFINED. THE
PROGRAM PROCEEDS TO THE NEXT CYCLE
113
PLATEAU TIMEOUT
VOLTAGE LEVEL HAS REMAINED CONSTANT FOR AN
EXTENDED TIME AND END-OF-CHARGE CONDITIONS
CANNOT BE MET
115
RESERVED
RESERVED
116
TARGET NOT MET
THE “TARGET CAPACITY” VALUE IN THE C-CODE HAS NOT
BEEN MET
118
RESERVED
RESERVED
119
WEAK BATTERY
BATTERY VOLTAGE FALLS BELOW THE END-OF-
DISCHARGE VOLTAGE (AS DEFINED IN THE C-CODE)
DURING AN OHMTEST
120
OVER VOLTAGE
THE BATTERY VOLTAGE IS HIGHER THAN THE “MAX. SAFE
OPERATING VOLTAGE” AS DEFINED IN THE C-CODE
121
REVERSED
BATTERY REVERSED
122
SHORTED
THE BATTERY VOLTAGE IS EITHER EXTREMELY LOW OR
THE TERMINALS HAVE BEEN SHORTED
123
L.V. TIMEOUT
BATTERY VOLTAGE IS BELOW 800mVcell FOR 1c-minute
(CHARGE CONDITION ONLY)
124
L.V. TIMEOUT
BATTERY VOLTAGE IS BELOW MINIMAL VOLTAGE LEVEL
FOR 10C-MINUTE. (CHARGE CONDITION ONLY). NiXX –
1144Mv, LA – 1990MV. LI-2000mV
125
NO SLOPE
NiXX ONLY. NO NEGATIVE SLOPE DETECTED
126
LOW VOLTAGE
ONE OR MORE CELLS WITHIN THE BATTERY PACK ARE
LOWER THAN THE “MIN. SAFE OPERATING VOLTAGE”
(DIVIDED BY THE NUMBER OF CELLS) AS DEFINED IN THE
C-CODE
127
LOW VOLTAGE
BATTERY VOLTAGE IS BELOW “MIN. SAFE OPERATING
VOLTAGE” AS DEFINED IN THE C-CODE
128
SOFT
NiXX ONLY. BATTERY VOLTAGE HAS REACHED THE “MIN.
SAFE OPERATING VOLTAGE” AS DEFINED IN THE C-CODE
129
RESERVED
RESERVED
130
CURRENT RISE
CURRENT IS INCREASING DURING A CONSTANT VOLTAGE
131
IMPED. SKIPPED
AC RESISTANCE TEST IS A STEP IN A PROGRAM AND HAS
BEEN SKIPPED, AS AC RESISTANCE TESTING CAN ONLY BE
PERFORMED ON CHANNEL 1
