C8000 Battery Testing System User Manual
276 5 Status Messages
AC IMPEDANCE TEST CAN BE PERFORMED ON CHANNEL 1
ONLY
AC IMPEDANCE MEASUREMENT VALUE IS OUT OF
MEASURABLE RANGE.
THE MAXIMUM DISCHARGE TIME HAS BEEN REACHED AS
DEFINED IN THE C-CODE. “DISCHARGE TIMEOUT”
THE MAXIMUM CHARGE TIME HAS BEEN REACHED AS
DEFINED IN THE C-CODE. “CHARGE TIMEOUT”
THE MAXIMUM DISCHARGE TIME HAS BEEN REACHED AS
DEFINED IN THE C-CODE. “DISCHARGE TIMEOUT” (NiXX
ONLY)
UNABLE TO READ THE THERMISTOR ATTACHED TO THE
POWER PORT CABLE
THE TEMPERATURE ROSE AT A RATE GREATER THAN 2°C
WITHIN 30 SECONDS
NO CURRENT OUTPUT HAS BEEN DETECTED FOR 1
MINUTE
THE STEP “PARALLEL DISCHARGE” IS BEING ATTEMPTED
TO BE RUN AND NO DUAL PORT CABLE IS ATTACHED TO
THE UNIT
DISCHARGE CURRENT TARGET CANNOT BE MET, BUT A
LOW RATE OF DISCHAGE WAS DETECTED
CHARGE CURRENT TARGET CANNOT BE MET, BUT A LOW
RATE OF CHARGE HAS BEEN DETECTED
AN ERROR WAS DETECTED WITH THE CALIBARATION
INFORMATION
ANALOG PORT VOLTAGE READING OUT OF RANGE
EXTERNAL SYSTEM TEMPERATURE IS ABOVE MAXIMUM
SYSTEM TEMPERATURE
REQUESTED TARGET CURRENT LEVEL IS GREATER THAN
THE SYSTEM MAXIMUM OUTPUT OF 10A PER CHANNEL
