C8000 Battery Testing System User Manual
54 2 Battery Tester
Edit the details as required and press OK to save the changes.
See Section 4 C-Code Parameters for system limitations during
C-code Creation.
A unique identification name for the C-
Code.
Selects the desired chemistry (Options:
SLA/NiCD/NiMH/Li/LiPH/Primary)
Enter the number of cells. Number of
cells supported by Battery chemistry:
NiCD and NiMH up to 30 cells in
series (36 Volts nominal).
SLA batteries up to 18 cells in
series (36 Volts nominal).
Li-ion batteries up to 10 cells in
series (36 Volts nominal).
LiPH batteries up to 10 cells in
series (32 Volts nominal).
Primary batteries up to 30 cells in
series (36 Volts nominal.
Discharge only).
The capacity rating of the cell(s) or
battery pack. Supported Range 0.050-100
(values are stated in Milli-amperage
hour (mAh)).
The rate of charge current to be applied.
(Unit (A))
