Shows, Memories and Presets
180 APOLLO
Digital Broadcast Production Console
FIG 6 - ISOLATING OUTPUT PORTSOutput port isolation
In addition to isolating paths (and possibly
their associated ports) from memory load
operations, output ports can have their
patching isolated. To do this, select an
output port and touch the ISO button as
shown in Fig 6. It will be highlighted with
an ISO icon as an indication that it is now
isolated.
Repeat the process to remove the
isolation.
Improvements to Memory Isolate
System
From V7.0 Mains, Auxes, and Tracks
can now be isolated in the same way as
Channels and Groups.
From V7.0, when a bus is patched to
a destination, and that destination is
isolated, the width of the relevant bus is
also isolated. This prevents an incoming
memory from changing the width of a bus,
and removing the isolated patches.
Conversely, and if appropriate, when a
bus is isolated, all the destinations to
which it is connected can also be isolated
automatically.
