Compressor
Threshold
+20dB to -20dB
Recovery
75ms to 4s + Auto
Ratio
1:1 up to 4:1 in 0.1 steps, 4:1 up to 10:1 in 0.2 steps, 10:1 up to
20:1 in 1.0 steps, 20:1, 25:1, 30:1, 35:1, 40:1, 50:1 (Limiter)
Attack
50µs to 200ms (5ms default)
Make Up Gain
0dB to 20dB
Expander
Threshold
+10dB to -40dB
Recovery
75ms to 4s + Auto
Depth
0dB to 40dB
Ratio
2:1 and Var (variable according to level)
Attack
300µs (fast) 16ms (normal)
FIG 2 - DYNAMICS PARAMETERS
Gate
Threshold
0dB to -40dB with 6dB hysteresis
Recovery
75ms to 4s + Auto
Depth
0dB to 40dB
Attack
300µs (fast) 16ms (normal)
Gate Delay
0s to 1s
