Back Side
0X7U-009
Sub-output tray (Back cover)
Open the sub-output tray when printing on the envelopes. When using a paper type that easily curls such as
labels, you can reduce curl by opening this tray ( Paper Curls(P. 511) ).
Ventilation slots
Air from inside the machine is vented out to cool down the inside of the machine. Note that placing objects in
front of the ventilation slots prevents ventilation. Installation(P. 3)
Power socket
Connect the power cord.
Duplex unit
If paper has jammed during 2-sided printing, remove this.
SD card slot cover
Open the SD card slot cover when installing the optional SD card. Installing an SD Card(P. 583)
USB port (for USB device connection)
Connect a USB device that is used with MEAP applications.
USB port (for computer connection)
Connect a USB cable when connecting the machine and a computer.
ACT indicator
The ACT indicator blinks while data is being sent or received.
Basic Operations
19
