Loading Paper in the Paper Drawer
0X7U-00U
Load the paper that you usually use in the paper drawer. When you want to print on paper that is not loaded in the
paper drawer, load the paper in the multi-purpose tray. Loading Paper in the Multi-Purpose Tray(P. 44)
Loading Standard Size Paper(P. 39)
Loading a Custom Size Paper(P. 41)
Paper Orientation
See the table below to load available paper in correct orientation.
Paper
Orientation
A4, A5 (portrait), A6 *1 , B5, Legal, Letter, Executive, Statement
*1
, Foolscap, 16K, Custom (portrait)
A5 (landscape)
*2
, Custom (landscape)
*1
Can be loaded only in the optional custom media cassette.
*2
Can be loaded only in the optional A5 cassette.
● Follow the procedure below when loading paper into the optional paper feeder.
Loading Standard Size Paper
To load paper whose size is found in the paper size markings on the paper drawer, use the following procedure. For
paper whose size is not found in the paper size markings, see Loading a Custom Size Paper(P. 41) .
1
Pull out the paper drawer until it stops, and remove it while lifting the front side.
2
Adjust the positions of the paper guides to the paper size you want to use.
● Press the lock release lever ( ) to align the projection ( ) to the appropriate paper size marking.
Basic Operations
39
To Next Page
