4021470 Rev D D9854 Advanced Program Receiver Installation and Operation Guide 4-45
4:3 4:3 4:3 P/B None Conversion is not possible.
Normal picture.
4:3 4:3 14:9 None Conversion is not possible.
Normal picture.
4:3 4:3 16:9 SCALE None Conversion is not possible.
Normal picture.
4:3 16:9 None None Picture is short & fat.
4:3 16:9 Auto 4:3 P/B Uses 4:3 P/B.
4:3 16:9 16:9 L/B None Conversion is not possible.
Picture appears short and fat.
4:3 16:9 4:3 CCO None Conversion is not possible.
Picture appears short and fat.
4:3 16:9 4:3 P/B 4:3 P/B 4:3 picture is centered in a
pillar-style box.
4:3 16:9 14:9 14:9 Compromises some up-
sampling. Some black bars
and cropping are visible.
4:3 16:9 16:9 SCALE 16:9
SCALE
Vertically up-samples the
centre of the 4:3 picture and
crops the top and bottom of
the screen.
16:9 16:9 None None Normal
Stream TV A/R Conversion Act Conv Description Image
