Setup Menu: Services, Continued
OSD Messages
Description: Sets whether alarms and warnings are to be displayed on the on-
screen display (e.g., TV monitor).
Parameters: Enable or Disable.
TV A/R
Description: This is the aspect ratio of your TV.
Parameters: 4:3 or 16:9 (wide aspect ratio). The default is 4:3. Set it to the
corresponding value.
Convert
Description: This is the conversion that the receiver will perform on the
incoming signal for the picture to be displayed correctly (i.e., to
correspond to the aspect ratio of your TV) on your TV, based on
your selection.
Parameters: Auto, None, Auto AFD (Auto setting using Active Format
Descriptor), 16:9 L/B (letter box), 4:3 P/B (pillar box), 14:9, 4:3 CCO
(Centre Cut Out), 16:9 SCALE. The default is set to Auto.
Stream
Description: This indicates the aspect ratio of the incoming signal. This is read-
only.
Act Conv
Description: This is the type of (aspect ratio) conversion the receiver will perform
based on what you have selected. This is read-only.
Refer to the following table for the conversions performed by the receiver based on
your selection, and the effect on the picture displayed by the receiver in each case
(without Auto AFD).
Stream TV A/R Conversion Act Conv Description Image
4:3 4:3 None None Normal Picture
4:3 4:3 Auto None No conversion
4:3 4:3 16:9 L/B None Conversion is not possible.
Normal picture.
4:3 4:3 4:3 CCO None Conversion is not possible.
Normal picture.
To Next Page
