4-64 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Setup Menu: Outputs, Continued
Tones
Description: These are the cue tone digits used in your network.
Parameters: 1 to 999.
Mode
Description: This option specifies what to transmit in the sequence.
Parameters: * for Start Tone, # for End Tone, and */# for transmitting the Start
Tone and then the End Tone after waiting the specified delay time
in the option below.
Delay (sec)
Description: This is the delay, in seconds, that is sent when */# is used in the
Mode option above.
Parameters: 1 to 255. The default is 30.
Relay Mode
Description: This relay can be programmed to respond to an Alarm state, or the
state of one of the eight cue trigger pins. The response is generated
at the Cue Tone/Relay output on the rear panel of the receiver.
Parameters: Alarm, Trigger.
The following table shows what the possible field settings are and
their relationship to the receiver output.
Cue Trigger Bit
Description: Select one of the eight Cue Trigger Bits corresponding to the Cue
Trigger port pins.
Parameters: 1 to 8.
Relay
Mode
Condition Relay Contact
NC - C C - NO
Alarm
Unit Power Off Open Close
Alarm State Open Close
No Alarm Close Open
Trigger Active (selected in
PNC)
Close Open
Inactive Open Close
