4021470 Rev D D9854 Advanced Program Receiver Installation and Operation Guide 4-67
Setup Menu: Outputs, Continued
User Rate (Mbps)
Description: This parameter controls the output rate. It is only used if Rate
Control is set to User. This setting is used when the signal source is
RF or ASI. Note that output data may be lost when the user-selected
bit rate is set to a value that is less than the actual signal bit rate.
This allows you to set the output bit rate to a value expected by
equipment connected to the ASI output.
Parameters: 0 to 213 Mbps.
Output Mode
Description: This selects the DPM output mode.
Parameters: No Output, Passthrough, Service Chans Only, MAP Passthrough,
MAP Svc Chans Only or Full DPM Control.
Output Mode Description
No Output No ASI output will be generated.
Passthrough The output will be identical to the input. The output
channel will not be modified.
PE/PID remapping options, PSI regeneration and User
Rate are not supported in this mode.
Service Chans Only Only service channels will be output.
MAP Passthrough The output will be identical to the input, except that it
will be generated using the DPM and PID mapping
settings.
MAP Svc Chans
Only
Only service channels will be output according to the
DPM and PID mapping settings.
Full DPM Control The output will be generated according to the DPM
settings on the DPM: ASI or MOIP1 menus. This is a
manual control setting.
