4-66 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Setup Menu: Outputs, Continued
TS OUT
ASI
Name
Description: This is the name assigned to the transport output for ease of
reference.
Parameters: 20-character string.
Rate Control
Description: This is the DPM output rate control (in Mbps) when using an RF
input source.
Parameters: Auto, User. The table below describes the affect each of the settings
has on the output bit rate.
Rate Control Description
Auto The output rate follows that set by the
uplink. The output rate will be the same as
the input rate (including all null packets).
This means the output bit rate is determined
automatically based on the input source
symbol rate and FEC value.
User The output rate is specified as the Output
Rate parameter. It is determined by the user
setting regardless of the input source.
