4021470 Rev D D9854 Advanced Program Receiver Installation and Operation Guide 4-69
Setup Menu: Outputs, Continued
Rate Control
Description: This is the DPM output rate control (in Mbps) when using an RF
input source.
Parameters: Auto, User. The table below describes the effect each of the settings
has on the output bit rate.
User Rate (Mbps)
Description: This parameter controls the output rate. It is only used if Rate
Control is set to User. This setting is used when the signal source is
RF or ASI. Note that output data may be lost when the user-selected
bit rate is set to a value that is less than the actual signal bit rate.
This allows you to set the output bit rate to a value expected by
equipment connected to the ASI output.
Parameters: 0 to 999.99999 Mbps.
Rate Control Description
Auto The output rate follows that set by the uplink. The output
rate will be the same as the input rate (including all null
packets). This means the output bit rate is determined
automatically based on the input source symbol rate and
FEC value.
User The output rate is specified as the Output Rate parameter. It
is determined by the user setting regardless of the input
source.
