5-14 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Frequency (GHz) The current downlink frequency, in GHz.
LBand (MHz) The current L-Band frequency, in MHz.
Symbol Rate (MSps) Symbol rate of the received signal, in Msymbols/
second.
FEC The FEC (Forward Error Correction) rate of the
received signal (N/A, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6,
7/8, 8/9 or 9/10).
Polarization The signal polarization setting. This setting is only
applicable when LNB Power is set to H-NIT or V-
NIT. The selected setting must match the
polarization of the transmitted signal. The
parameters are: Horiz (Horizontal), Vert (Vertical)
or Auto.
Modulation The modulation type for the received signal (N/A,
QPSK, 8PSK, DVB-S or DVB-S2).
I/Q The IQ (Input Signal Inversion) for the received
signal (Inv or NonInv).
PVBer The PV (Post-Viterbi) BER for the received signal
(DVB-S).
C/N (dB) Current Carrier-to-Noise ratio, in dB.
C/N Margin (dB) Current Carrier-to-Noise Margin for the received
signal. The Carrier-to-Noise margin is the actual
distance that C/N is from the noise threshold.
Values can be displayed in the range of -32.0 to
+30.0 dB.
Corrected Errors Current Corrected Error Count for the received
signal.
Uncorrected Errors Current Uncorrected Error Count for the received
signal.
LNB Status Current LNB connection status (No Load,
Overloaded, OverTemp, Short Circuit, Disabled,
Normal or N/A).
Parameter Description
