5-38 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Configuring the Transport Stream: DPM Global, Continued
8. In the Service ID Output drop-down, select whether the receiver should always
generate PSI tables for the Mapped PE even if the selected input channel is not
available, or for only valid service channels/IDs. The following table describes
each service ID:
9. Select the DPM Regeneration Rate Option. This applies the PowerVu rates
(consistent with the uplink). This parameter is only used if Remapping Control
is set to None. The following table describes each PSI rate:
10. The PSI Table Output Option drop-down allows the operator to specify which
PSI tables to include in the program/output stream. The following table
describes each option:
11. Click Save.
Svc ID Description
Valid Ch Only transmits the PSI tables for the mapped program if
the program exists on the input stream.
All Ch Transmits the PSI tables for the mapped program even
if the program does not exist in the input stream.
All Ch is only valid if the PAT, NIT, SDT and PMT are
set to Regenerate.
PSI Rate Description
Auto Matches the generated PSI tables' output rate as the
incoming rate.
MPEG Min Transmits the generated PSI tables on the longest
intervals that are allowed by MPEG standard.
SA Std Transmits the generated PSI tables based on PowerVu
standard intervals.
PSI Options Description
Pass All Transmits the incoming PSI Tables as is; does not
modify the content and rate.
Drop All Does not transmit any PSI Tables.
Ctl By Table The operator can enter the Tables menu to select the
output mode for each table. The default table selections
will be all pass, and only with CDT dropped.
To Next Page
