4021470 Rev D D9854 Advanced Program Receiver Installation and Operation Guide 4-11
Startup Screen, Continued
Assigning a Program to the Program Entry
To assign a program to the PE:
1. Press MENU until you display the startup screen.
The PE (Program Entry) channel is initially displayed.
Note: PE1 is the default.
2. Press the ADV key to select PE1.
3. Press the UP or DOWN arrow key to scroll through the available program
entries.
4. Press ADV again to select the channel number.
5. Directly enter the channel number using the 0 to 9 keys.
s
PE1 706 Channel Name
RF1 Freq:12.658 Lvl:-50 Marg:11.6
Ch #PE #
s
PE1 1 Channel Name
RF1 Freq:12.658 Lvl:-50 Marg:11.6
PE
s
PE1 1 Channel Name
RF1 Freq:12.658 Lvl:-50 Marg:11.6
Ch #

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
