Cisco IE-3000-8TC Command Reference

2-237
Cisco IE 3000 Switch Command Reference
OL-13019-01
Chapter 2 IE 3000 Switch Cisco IOS Commands
mls qos srr-queue input dscp-map
mls qos srr-queue input dscp-map
Use the mls qos srr-queue input dscp-map global configuration command to map Differentiated
Services Code Point (DSCP) values to an ingress queue or to map DSCP values to a queue and to a
threshold ID. Use the no form of this command to return to the default setting.
mls qos srr-queue input dscp-map queue queue-id {dscp1...dscp8 | threshold threshold-id
dscp1...dscp8}
no mls qos srr-queue input dscp-map
Syntax Description
Defaults Table 2-12 shows the default DSCP input queue threshold map:
Command Modes Global configuration
Command History
Usage Guidelines The DSCP assigned at the ingress port selects an ingress or egress queue and threshold.
The drop-threshold percentage for threshold 3 is predefined. It is set to the queue-full state. You can
assign two weighted tail-drop (WTD) threshold percentages to an ingress queue by using the mls qos
srr-queue input threshold global configuration command.
queue queue-id Specify a queue number.
For queue-id, the range is 1 to 2.
dscp1...dscp8 Map DSCP values to an ingress queue.
For dscp1...dscp8, enter up to eight values, and separate each value with a
space. The range is 0 to 63.
threshold threshold-id
dscp1...dscp8
Map DSCP values to a queue threshold ID.
For threshold-id, the range is 1 to 3.
For dscp1...dscp8, enter up to eight values, and separate each value with a
space. The range is 0 to 63.
Ta b l e 2-12 Default DSCP Input Queue Threshold Map
DSCP Value Queue ID–Threshold ID
0–39 1–1
40–47 2–1
48–63 1–1
Release Modification
12.2(44)EX This command was introduced.

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
