Cisco IE-3000-8TC Command Reference

2-496
Cisco IE 3000 Switch Command Reference
OL-13019-01
Chapter 2 IE 3000 Switch Cisco IOS Commands
snmp-server host
snmp-server host
Use the snmp-server host global configuration command to specify the recipient (host) of a Simple
Network Management Protocol (SNMP) notification operation. Use the no form of this command to
remove the specified host.
snmp-server host host-addr [informs | traps] [version {1 | 2c | 3 {auth | noauth| priv}] [vrf
vrf-instance] {community-string [notification-type]}
no snmp-server host host-addr [informs | traps] [version {1 | 2c | 3 {auth | noauth | priv}] [vrf
vrf-instance] community-string
Syntax Description host-addr Name or Internet address of the host (the targeted recipient).
udp-port port (Optional) Configure the User Datagram Protocol (UDP) port number of the
host to receive the traps. The range is 0 to 65535.
informs | traps (Optional) Send SNMP traps or informs to this host.
version 1 | 2c | 3 (Optional) Version of the SNMP used to send the traps.
These keywords are supported:
1—SNMPv1. This option is not available with informs.
2c—SNMPv2C.
3—SNMPv3. These optional keywords can follow the Version 3 keyword:
• auth (Optional). Enables Message Digest 5 (MD5) and Secure Hash
Algorithm (SHA) packet authentication.
• noauth (Default). The noAuthNoPriv security level. This is the default
if the [auth | noauth | priv] keyword choice is not specified.
• priv (Optional). Enables Data Encryption Standard (DES) packet
encryption (also called privacy).
Note The priv keyword is available only when the cryptographic
(encrypted) software image is installed.
vrf vrf-instance (Optional) Virtual private network (VPN) routing instance and name for this
host.

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
