Cisco IE-3000-8TC Command Reference

2-364
Cisco IE 3000 Switch Command Reference
OL-13019-01
Chapter 2 IE 3000 Switch Cisco IOS Commands
show fcs-threshold
show fcs-threshold
Use the show fcs-threshold user EXEC command to display the frame check sequence (FCS) bit
error-rate settings on the switch interfaces.
show fcs-threshold [ | {begin | exclude | include} expression]
Syntax Description
Command Modes User EXEC
Command History
Usage Guidelines The Ethernet standard calls for a maximum bit error rate of 10
-8
. In the Cisco IE 3000 switch, the
configurable bit error-rate range is from 10
-6
to 10
-11
. The bit error-rate input to the switch is a positive
exponent. The output displays the positive exponent; an output of 9 means that the bit error-rate is 10
-9
.
Expressions are case sensitive. For example, if you enter | exclude output, the lines that contain output
do not appear, but the lines that contain Output appear.
Examples This is an example of output from the show fcs-threshold command. It shows the output when all ports
are set to the default FCS threshold.
Switch# show fcs-threshold
Port FCS Threshold
Fa1/1 8
Fa1/2 8
Fa1/3 8
Fa1/4 8
Fa2/1 8
Fa2/2 8
Fa2/3 8
Fa2/4 8
Fa2/5 8
Fa2/6 8
Fa2/7 8
Fa2/8 8
Fa3/1 8
Fa3/2 8
Fa3/3 8
Fa3/4 8
Fa3/5 8
Fa3/6 8
Fa3/7 8
| begin (Optional) Display begins with the line that matches the expression.
| exclude (Optional) Display excludes lines that match the expression.
| include (Optional) Display includes lines that match the specified expression.
expression Expression in the output to use as a reference point.
Release Modification
12.2(44)EX This command was introduced.

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
