Cisco IE-3000-8TC Command Reference

2-23
Cisco IE 3000 Switch Command Reference
OL-13019-01
Chapter 2 IE 3000 Switch Cisco IOS Commands
auto qos voip
Table 2-3 shows the generated auto-QoS configuration for the ingress queues.
Table 2-4 shows the generated auto-QoS configuration for the egress queues.
Command Modes Interface configuration
Command History
Usage Guidelines Use this command to configure the QoS appropriate for VoIP traffic within the QoS domain. The QoS
domain includes the switch, the interior of the network, and edge devices that can classify incoming
traffic for QoS.
Auto-QoS configures the switch for VoIP with Cisco IP Phones on switch and routed ports and for VoIP
with devices running the Cisco SoftPhone application. These releases support only Cisco IP SoftPhone
Version 1.3(3) or later. Connected devices must use Cisco Call Manager Version 4 or later.
The show auto qos command output shows the service policy information for the Cisco IP phone.
To take advantage of the auto-QoS defaults, you should enable auto-QoS before you configure other QoS
commands. You can fine-tune the auto-QoS configuration after you enable auto-QoS.
Note The switch applies the auto-QoS-generated commands as if the commands were entered from the
command-line interface (CLI). An existing user configuration can cause the application of the generated
commands to fail or to be overridden by the generated commands. These actions occur without warning.
If all the generated commands are successfully applied, any user-entered configuration that was not
Ta b l e 2-3 Auto-QoS Configuration for the Ingress Queues
Ingress Queue Queue Number CoS-to-Queue Map
Queue Weight
(Bandwidth)
Queue (Buffer)
Size
SRR
1
shared
1. SRR = shaped round robin. Ingress queues support shared mode only.
1 0, 1 81 percent 67 percent
Priority 2 2, 3, 4, 5, 6, 7 19 percent 33 percent
Ta b l e 2-4 Auto-QoS Configuration for the Egress Queues
Egress Queue Queue Number CoS-to-Queue Map
Queue Weight
(Bandwidth)
Queue (Buffer) Size
for Gigabit-Capable
Ports
Queue (Buffer)
Size for 10/100
Ethernet Ports
Priority (shaped) 1 5 up to100 percent 16 percent 10 percent
SRR shared 2 3, 6, 7 10 percent 6 percent 10 percent
SRR shared 3 2, 4 60 percent 17 percent 26 percent
SRR shared 4 0, 1 20 percent 61 percent 54 percent
Release Modification
12.2(40)SE The information in the command output changed.
12.2(44)EX This command was introduced.

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
