2-245
Cisco IE 3000 Switch Command Reference
OL-13019-01
Chapter 2 IE 3000 Switch Cisco IOS Commands
mls qos srr-queue output dscp-map
mls qos srr-queue output dscp-map
Use the mls qos srr-queue output dscp-map global configuration command to map Differentiated
Services Code Point (DSCP) values to an egress or to map DSCP values to a queue and to a threshold
ID. Use the no form of this command to return to the default setting.
mls qos srr-queue output dscp-map queue queue-id {dscp1...dscp8 | threshold threshold-id
dscp1...dscp8}
no mls qos srr-queue output dscp-map
Syntax Description
Defaults Table 2-14 shows the default DSCP output queue threshold map:
Command Modes Global configuration
Command History
queue queue-id Specify a queue number.
For queue-id, the range is 1 to 4.
dscp1...dscp8 Map DSCP values to an egress queue.
For dscp1...dscp8, enter up to eight values, and separate each value with a
space. The range is 0 to 63.
threshold threshold-id
dscp1...dscp8
Map DSCP values to a queue threshold ID.
For threshold-id, the range is 1 to 3.
For dscp1...dscp8, enter up to eight values, and separate each value with a
space. The range is 0 to 63.
Ta b l e 2-14 Default DSCP Output Queue Threshold Map
DSCP Value Queue ID–Threshold ID
0–15 2–1
16–31 3–1
32–39 4–1
40–47 1–1
48–63 4–1
Release Modification
12.2(44)EX This command was introduced.
