Cisco IE-3000-8TC Command Reference

2-456
Cisco IE 3000 Switch Command Reference
OL-13019-01
Chapter 2 IE 3000 Switch Cisco IOS Commands
show policy-map
show policy-map
Use the show policy-map user EXEC command to display quality of service (QoS) policy maps, which
define classification criteria for incoming traffic. Policy maps can include policers that specify the
bandwidth limitations and the action to take if the limits are exceeded.
show policy-map [policy-map-name [class class-map-name]] [ | {begin | exclude | include}
expression]
Syntax Description
Note Though visible in the command-line help string, the control-plane and interface keywords are not
supported, and the statistics shown in the display should be ignored.
Command Modes User EXEC
Command History
Usage Guidelines Expressions are case sensitive. For example, if you enter | exclude output, the lines that contain output
do not appear, but the lines that contain Output appear.
Examples This is an example of output from the show policy-map command:
Switch> show policy-map
Policy Map videowizard_policy2
class videowizard_10-10-10-10
set dscp 34
police 100000000 2000000 exceed-action drop
Policy Map mypolicy
class dscp5
set dscp 6
policy-map-name (Optional) Display the specified policy-map name.
class class-map-name (Optional) Display QoS policy actions for a individual class.
| begin (Optional) Display begins with the line that matches the expression.
| exclude (Optional) Display excludes lines that match the expression.
| include (Optional) Display includes lines that match the specified expression.
expression Expression in the output to use as a reference point.
Release Modification
12.2(44)EX This command was introduced.

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
