Cisco IE-3000-8TC Command Reference

2-334
Cisco IE 3000 Switch Command Reference
OL-13019-01
Chapter 2 IE 3000 Switch Cisco IOS Commands
show controllers ethernet-controller
This is an example of output from the show controllers ethernet-controller phy command for a specific
interface:
Switch# show controllers ethernet-controller gigabitethernet1/1 phy
GigabitEthernet1/1 (gpn: 1, port-number: 1)
-----------------------------------------------------------
General SFP Information
-----------------------------------------------
Identifier : 0x03
Connector : 0x00
Transceiver : 0x00 0x00 0x00 0x08 0x00 0x00 0x00 0x00
Encoding : 0x01
BR_Nominal : 0x0D
Vendor Name : CISCO-METHODE
Vendor Part Number : SP7041
Vendor Revision : 0x43 0x20 0x20 0x20
Vendor Serial Number : 00000MTC1017075F
-----------------------------------------------
Other Information
-------------------------------------------------------
Port asic num : 0
Port asic port num : 0
XCVR init completed : 0
Embedded PHY : not present
SFP presence index : 0
SFP iter cnt : 30
SFP failed oper flag : 0x0
IIC error cnt : 0
IIC error dsb cnt : 0
IIC max sts cnt : 50
Chk for link status : 1
Link Status : 1
Link Status Media : 2
This is an example of output from the show controllers ethernet-controller port-asic configuration
command:
Switch# show controllers ethernet-controller port-asic configuration
========================================================================
Switch 1, PortASIC 0 Registers
------------------------------------------------------------------------
DeviceType : 000101BC
Reset : 00000000
PmadMicConfig : 00000001
PmadMicDiag : 00000003
SupervisorReceiveFifoSramInfo : 000007D0 000007D0 40000000
SupervisorTransmitFifoSramInfo : 000001D0 000001D0 40000000
System FCS error frames The total number of frames received on an interface that have a valid length (in bytes) but that do
not have the correct FCS values.
RxPortFifoFull drop
frames
The total number of frames received on an interface that are dropped because the ingress queue
is full.
1. FCS = frame check sequence
2. MTU = maximum transmission unit
Table 2-20 Receive Field Descriptions (continued)
Field Description

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
