Cisco IE-3000-8TC Command Reference

2-343
Cisco IE 3000 Switch Command Reference
OL-13019-01
Chapter 2 IE 3000 Switch Cisco IOS Commands
show dot1x
SuppTimeout = 30
ReAuthPeriod = 3600 (Locally configured)
ReAuthMax = 2
MaxReq = 2
TxPeriod = 30
RateLimitPeriod = 0
Dot1x Authenticator Client List Empty
This is an example of output from the show dot1x interface interface-id details commmand when a port
is assigned to a guest VLAN and the host mode changes to multiple-hosts mode:
Switch# show dot1x interface gigabitethernet1/1 details
Dot1x Info for GigabitEthernet1/1
-----------------------------------
PAE = AUTHENTICATOR
PortControl = AUTO
ControlDirection = Both
HostMode = SINGLE_HOST
ReAuthentication = Enabled
QuietPeriod = 60
ServerTimeout = 30
SuppTimeout = 30
ReAuthPeriod = 3600 (Locally configured)
ReAuthMax = 2
MaxReq = 2
TxPeriod = 30
RateLimitPeriod = 0
Guest-Vlan = 182
Dot1x Authenticator Client List Empty
Port Status = AUTHORIZED
Authorized By = Guest-Vlan
Operational HostMode = MULTI_HOST
Vlan Policy = 182
This is an example of output from the show dot1x interface interface-id statistics command. Table 2-22
describes the fields in the display.
Switch> show dot1x interface gigabitethernet1/2 statistics
Dot1x Authenticator Port Statistics for GigabitEthernet1/2
--------------------------------------------
RxStart = 0 RxLogoff = 0 RxResp = 1 RxRespID = 1
RxInvalid = 0 RxLenErr = 0 RxTotal = 2
TxReq = 2 TxReqID = 132 TxTotal = 134
RxVersion = 2 LastRxSrcMAC = 00a0.c9b8.0072
Ta b l e 2-22 show dot1x statistics Field Descriptions
Field Description
RxStart Number of valid EAPOL-start frames that have been received.
RxLogoff Number of EAPOL-logoff frames that have been received.
RxResp Number of valid EAP-response frames (other than response/identity frames) that
have been received.
RxRespID Number of EAP-response/identity frames that have been received.

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
