Chapter 2 IE 3000 Switch Cisco IOS Commands
show vtp
This is an example of output from the show vtp status command. Table 2-35 describes each field in the
display.
Switch> show vtp status
VTP Version : 2
Configuration Revision : 0
Maximum VLANs supported locally : 1005
Number of existing VLANs : 45
VTP Operating Mode : Transparent
VTP Domain Name : shared_testbed1
VTP Pruning Mode : Disabled
VTP V2 Mode : Disabled
VTP Traps Generation : Enabled
MD5 digest : 0x3A 0x29 0x86 0x39 0xB4 0x5D 0x58 0xD7
Number of configuration
digest errors
Number of MD5 digest errors.
Digest errors increment whenever the MD5 digest in the summary packet
and the MD5 digest of the received advertisement calculated by the
switch do not match. This error usually means that the VTP password in
the two switches is different. To solve this problem, make sure the VTP
password on all switches is the same.
These errors mean that the switch is filtering incoming advertisements,
which causes the VTP database to become unsynchronized across the
network.
Number of V1 summary
errors
Number of Version 1 errors.
Version 1 summary errors increment whenever a switch in VTP V2 mode
receives a VTP Version 1 frame. These errors mean that at least one
neighboring switch is either running VTP Version 1 or VTP Version 2
with V2-mode disabled. To solve this problem, change the configuration
of the switches in VTP V2-mode to disabled.
Join Transmitted Number of VTP pruning messages sent on the trunk.
Join Received Number of VTP pruning messages received on the trunk.
Summary Advts Received
from non-pruning-capable
device
Number of VTP summary messages received on the trunk from devices
that do not support pruning.
Table 2-34 show vtp counters Field Descriptions (continued)
Field Description
Ta b l e 2-35 show vtp status Field Descriptions
Field Description
VTP Version Displays the VTP version operating on the switch. By default, the switch
implements Version 1 but can be set to Version 2.
Configuration Revision Current configuration revision number on this switch.
Maximum VLANs
Supported Locally
Maximum number of VLANs supported locally.
Number of Existing
VLANs
Number of existing VLANs.

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
