Cisco IE-3000-8TC Command Reference

2-533
Cisco IE 3000 Switch Command Reference
OL-13019-01
Chapter 2 IE 3000 Switch Cisco IOS Commands
spanning-tree mst root
When you enter the spanning-tree mst instance-id root secondary command, because of support for
the extended system ID, the software changes the switch priority from the default value (32768) to
28672. If the root switch fails, this switch becomes the next root switch (if the other switches in the
network use the default switch priority of
32768 and are therefore unlikely to become the root switch).
Examples This example shows how to configure the switch as the root switch for instance 10 with a network
diameter of 4:
Switch(config)# spanning-tree mst 10 root primary diameter 4
This example shows how to configure the switch as the secondary root switch for instance 10 with a
network diameter of 4:
Switch(config)# spanning-tree mst 10 root secondary diameter 4
You can verify your settings by entering the show spanning-tree mst instance-id privileged EXEC
command.
Related Commands Command Description
show spanning-tree mst instance-id Displays MST information for the specified instance.
spanning-tree mst forward-time Sets the forward-delay time for all MST instances.
spanning-tree mst hello-time Sets the interval between hello BPDUs sent by root switch
configuration messages.
spanning-tree mst max-age Sets the interval between messages that the spanning tree
receives from the root switch.
spanning-tree mst max-hops Sets the number of hops in a region before the BPDU is
discarded.

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
