Cisco IE-3000-8TC Command Reference

2-606
Cisco IE 3000 Switch Command Reference
OL-13019-01
Chapter 2 IE 3000 Switch Cisco IOS Commands
vlan (VLAN configuration)
media {ethernet | fddi |
fd-net | tokenring | tr-net}
(Optional) Specify the VLAN media type. Table 2-38 lists the valid
syntax for each media type.
• ethernet is Ethernet media type (the default).
• fddi is FDDI media type.
• fd-net is FDDI network entity title (NET) media type.
• tokenring is Token Ring media type if the VTP v2 mode is
disabled, or TrCRF if the VTP v2 mode is enabled.
• tr-net is Token Ring network entity title (NET) media type if the
VTP v2 mode is disabled or TrBRF media type if the VTP v2 mode
is enabled.
mtu mtu-size (Optional) Specify the maximum transmission unit (MTU) (packet size
in bytes). The range is 1500 to 18190.
name vlan-name (Optional) Specify the VLAN name, an ASCII string from 1 to 32
characters that must be unique within the administrative domain.
parent parent-vlan-id (Optional) Specify the parent VLAN of an existing FDDI, Token Ring,
or TrCRF VLAN. This parameter identifies the TrBRF to which a
TrCRF belongs and is required when defining a TrCRF. The range is 0
to 1005.
ring ring-number (Optional) Specify the logical ring for an FDDI, Token Ring, or TrCRF
VLAN. The range is 1 to 4095.
said said-value (Optional) Enter the security association identifier (SAID) as
documented in IEEE 802.10. The range is 1 to 4294967294, and the
number must be unique within the administrative domain.
state {suspend | active} (Optional) Specify the VLAN state:
• If active, the VLAN is operational.
• If suspend, the VLAN is suspended. Suspended VLANs do not
pass packets.
ste ste-number (Optional) Specify the maximum number of spanning-tree explorer
(STE) hops. This keyword applies only to TrCRF VLANs. The range is
0 to 13.
stp type {ieee | ibm | auto} (Optional) Specify the spanning-tree type for FDDI-NET, Token
Ring-NET, or TrBRF VLAN.
• ieee for IEEE Ethernet STP running source-route transparent
(SRT) bridging.
• ibm for IBM STP running source-route bridging (SRB).
• auto for STP running a combination of source-route transparent
bridging (IEEE) and source-route bridging (IBM).
tb-vlan1 tb-vlan1-id
and tb-vlan2 tb-vlan2-id
(Optional) Specify the first and second VLAN to which this VLAN is
translationally bridged. Translational VLANs translate FDDI or Token
Ring to Ethernet, for example. The range is 0 to 1005. Zero is assumed
if no value is specified.

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
