Chapter 13 Configuring CEF for PFC2 and PFC3A
Understanding How Layer 3 Switching Works
Understanding IPX Unicast Rewrite
Received IPX packets are (conceptually) formatted as follows:
After the switch rewrites an IPX packet, it is (conceptually) formatted as follows:
Understanding IP Multicast Rewrite
Received IP multicast packets are (conceptually) formatted as follows:
After the switch rewrites an IP multicast packet, it is (conceptually) formatted as follows:
Layer 2 Frame Header Layer 3 IPX Header Data FCS
Destination Source Checksum/
IPX Length/
Transport Control
Destination Net/
Node/
Socket
Source Net/
Node/
Socket
MSFC2 MAC Source A MAC n Destination B IPX Source A IPX
Layer 2 Frame Header Layer 3 IPX Header Data FCS
Destination Source Checksum/
IPX Length/
Transport Control
Destination Net/
Node/
Socket
Source Net/
Node/
Socket
Destination B
MAC
MSFC2 MAC n+1 Destination B IPX Source A IPX
Layer 2 Frame Header Layer 3 IP Header Data FCS
Destination Source Destination Source TTL Checksum
Group G1 MAC
1
1. In this example, Destination B is a member of Group G1.
Source A MAC Group G1 IP Source A IP n calculation1
Frame Header IP Header Data FCS
Destination Source Destination Source TTL Checksum
Group G1 MAC MSFC2/MSFC3
MAC
Group G1 IP Source A IP n–1 calculation2
