13-21
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 13 Configuring CEF for PFC2 and PFC3A
Configuring CEF for PFC2/PFC3A on the Switch
Displaying IP Multicast Information on MSFC2/MSFC3
These sections describe displaying IP multicast information on MSFC2/MSFC3:
• Displaying IP MMLS Interface Information, page 13-21
• Displaying the IP Multicast Routing Table, page 13-21
• Displaying IP Multicast Details, page 13-22
• Using the Debug Commands, page 13-24
• Using the Debug Commands on the SCP, page 13-24
Displaying IP MMLS Interface Information
The show ip pim interface count command displays the IP MMLS enable state on MSFC2/MSFC3 IP
PIM interfaces and the number of packets that are received and sent on the interface. The output lists the
PIM interfaces that are fast switched and process switched, and the packet counts for these interfaces.
An “H” is displayed on interfaces where IP MMLS is enabled.
The show ip interface command displays the IP MMLS enable state on an MSFC2/MSFC3 interface.
To display IP MMLS information for an IP PIM MSFC2/MSFC3 interface, perform one of these tasks:
This example shows how to display information about the IP MMLS interfaces:
Router# show ip pim interface count
States: FS - Fast Switched, H - Hardware Switched
Address Interface FS Mpackets In/Out
192.168.10.2 Vlan10 * H 40886/0
192.168.11.2 Vlan11 * H 0/40554
192.168.12.2 Vlan12 * H 0/40554
192.168.23.2 Vlan23 * 0/0
192.168.24.2 Vlan24 * 0/0
Router#
Displaying the IP Multicast Routing Table
The show ip mroute command displays the IP multicast routing table on MSFC2/MSFC3.
To display the IP multicast routing table, perform this task:
Task Command
Display IP MMLS interface information. Router# show ip pim interface [type number] count
Display the IP MMLS interface enable state. Router# show ip interface
Task Command
Display the IP multicast routing table. Router# show ip mroute [group[source]] |
[summary] | [count] | [active kbps]
